OEM AIRMAX 88.6515

Genuine Airmax NFPA pneumatic cylinder 88.6515

Genuine Airmax Series 88 double-acting NFPA square-head air cylinder, OEM part number 88.6515, with a 4 in. bore and 15 in. stroke for industrial automation and production equipment. Delivers rated force with self-lubricating construction. In stock in Canada with fast Eastern Canada shipping.

Fits (reference — verify by serial or BOM): Airmax Series 88 NFPA cylinder mounting per ANSI (NFPA) T3.6.7 R2-1996.

• OEM part number: 88.6515

Specifications:

• Bore: 4 in.
• Stroke: 15 in.
• Maximum working pressure: 250 PSI
• Operating pressure range: 0.05 to 1 MPa
• Ambient temperature: 5 to 60 C (40 to 140 F), no freezing
• Speed range: 50 to 500 mm/sec
• Theoretical force at 100 PSI: 1257 lbs out / 1178 lbs in
• Construction: hard-anodized aluminum tube, oil-filled alloy housing and bushing for self-lubrication (no added lubrication required)

Why replace on schedule: a scored bore or worn seals cause air bypass, lost force and rod creep; replace per OEM interval.

Canada Compressor Parts is an independent supplier of genuine Airmax parts. Airmax and all OEM names and part numbers are the property of their respective owners.
