Genuine AIRMAX NFPA pneumatic cylinder 88.6504 — 4 in. bore x 4 in. stroke
Genuine AIRMAX Series 88 NFPA pneumatic cylinder, OEM part number 88.6504, with a 4 in. (100 mm) bore and 4 in. stroke rated to 250 PSI. The hard-anodized aluminum tube gives low-friction, corrosion- and abrasion-resistant service, and a self-lubricating rod bushing means no external lubrication is required. In stock in Canada with fast Eastern Canada shipping.
Fits (reference — verify by serial or BOM): AIRMAX Series 88 NFPA square-head industrial cylinder mountings per ANSI (NFPA) T3.6.7 R2-1996.
- OEM part number: 88.6504
Specifications:
- Bore: 4 in. (100 mm)
- Stroke: 4 in.
- Maximum working pressure: 250 PSI
- Operating pressure range: 0.05 to 1 MPa
- Speed range: 50 to 500 mm/sec
- Ambient temperature: 5°C to 60°C (40°F to 140°F), no freezing
- Rod thread (KK): 3/4-16
- Port size (EE): 1/2 in.
- Construction: hard-anodized aluminum tube, self-lubricating rod bushing
Why replace on schedule: a worn cylinder loses seal integrity and actuation force; replace per OEM interval to keep machine cycles accurate.
Canada Compressor Parts is an independent supplier of genuine AIRMAX parts. AIRMAX and all OEM names and part numbers are the property of their respective owners.
