OEM AIRMAX 88.6404

Genuine AIRMAX NFPA pneumatic cylinder 88.6404

Genuine AIRMAX NFPA pneumatic cylinder, OEM part number 88.6404, with a 3-1/4 in. bore and 4 in. stroke rated to 250 PSI. The hard-anodized aluminum tube resists corrosion and abrasion for reliable industrial actuation. In stock in Canada with fast Eastern Canada shipping.

Fits (reference): AIRMAX Series 88 NFPA-interchangeable cylinders.

• OEM part number: 88.6404

Specifications:

• Bore: 3-1/4 in. (80 mm)
• Stroke: 4 in.
• Maximum working pressure: 250 PSI
• Operating pressure range: 0.05 to 1 MPa
• Speed range: 50 to 500 mm/sec
• Ambient temperature: 5 C to 60 C (40 F to 140 F), no freezing
• Tube: hard-anodized aluminum

Canada Compressor Parts is an independent supplier of genuine AIRMAX parts. AIRMAX and all OEM names and part numbers are the property of their respective owners.
