OEM AIRMAX 78.5422

Genuine Airmax Series 78 Double-Solenoid Valve 78.5422

Genuine Airmax Series 78 double-solenoid pneumatic valve, OEM part number 78.5422, a 5/3 exhaust-centered directional valve with 1/4 in NPT ports and a 12 VDC coil. The solid aluminum body, DIN connector and easy manual override give dependable directional control in pneumatic circuits. Restores rated performance and protects downstream equipment. In stock in Canada with fast Eastern Canada shipping.

Fits (reference — verify by serial or BOM): directional control in industrial pneumatic circuits.

• OEM part number: 78.5422
• Replacement solenoid: 78.5182

Specifications:

• Port size: 1/4 in NPT
• Cv: 1.4
• Voltage: 12 VDC
• Configuration: double solenoid, exhaust centered (5/3)
• Max working pressure: 150 PSI
• Working temperature: -10°C to 50°C (14°F to 122°F)
• Construction: solid aluminum body, DIN connector, manual override

Why replace on schedule: a sticking valve causes erratic actuation and air leakage that raises energy cost; replace per OEM interval.

Canada Compressor Parts is an independent supplier of genuine Airmax parts. Airmax and all OEM names and part numbers are the property of their respective owners.
