OEM AIRMAX 78.5322

Genuine AIRMAX Double Solenoid Valve 78.5322

Genuine AIRMAX Series 78 double solenoid valve, OEM part number 78.5322, for pneumatic cylinder control that needs a blocked mid-position. Spring-centered 5/3 closed-center valve holds position on signal loss. In stock in Canada with fast Eastern Canada shipping.

• OEM part number: 78.5322
• Function: 5-way / 3-position closed-center, spring centered
• Port thread: 1/4 in. NPT
• Cv: 1.4
• Voltage: 12 VDC
• Max working pressure: 150 PSI
• Working temperature: -10 C to 50 C (14 F to 122 F)
• Replacement coil: 78.5182

Why it matters: a closed-center valve locks the cylinder mid-stroke for safe stops.

Canada Compressor Parts is an independent supplier of genuine AIRMAX parts. AIRMAX and all OEM names and part numbers are the property of their respective owners.
