OEM AIRMAX 78.1352

Genuine AIRMAX Vertical Solenoid Valve 78.1352

Genuine AIRMAX Series 78 vertical solenoid valve, OEM part number 78.1352, a direct-acting normally-closed 2/2 valve with 1/4 in. NPT ports and a 12 VDC coil. Switches water, compressed air and oil service from an electrical signal using a single moving part. In stock in Canada with fast Eastern Canada shipping.

• OEM part number: 78.1352
• Normally-open equivalent: 78.1362
• Replacement coil: 78.1082 (12 VDC)

Specifications:

• Function: direct-acting vertical solenoid valve, normally closed
• Port size: 1/4 in. NPT
• Cv: 0.266
• Voltage: 12 VDC
• Working temperature: -10 to 90 C (14 to 194 F)
• Response time: 16 to 36 ms per complete cycle
• Construction: brass body, stainless steel operator, Viton seal

Why replace on schedule: a sticking or leaking solenoid valve disrupts circuit control and wastes air; replace when response slows or seals leak.

Canada Compressor Parts is an independent supplier of genuine AIRMAX parts. AIRMAX and all OEM names and part numbers are the property of their respective owners.
