OEM AIRMAX 78.1346

Genuine Airmax solenoid valve 78.1346

Genuine Airmax solenoid valve, OEM part number 78.1346, for compressed-air, water and oil on/off control in pneumatic systems. The Series 78 two-way, vertical, normally-open design switches flow cleanly and protects downstream equipment. In stock in Canada with fast Eastern Canada shipping.

Specifications:

• Type: 2-way solenoid valve, vertical, normally open
• Port size: 1/8 in NPT (orifice 2.4 / 3.0 mm)
• Cv: 0.224
• Voltage: 24 VAC
• Max working pressure: 200 PSI
• Response time: 16-36 ms full cycle
• OEM part number: 78.1346

Why replace on schedule: a worn solenoid valve leaks or fails to seat, wasting compressed air and disrupting process control; replace per OEM interval.

Canada Compressor Parts is an independent supplier of genuine Airmax parts. Airmax and all OEM names and part numbers are the property of their respective owners.
