OEM AIRMAX 78.1342

Genuine Airmax Solenoid Valve 78.1342

Genuine Airmax (Air Max Industries) solenoid valve, OEM part number 78.1342, from the Series 78 vertical valve range. A 2-way / 2-position normally-open valve for water, compressed air and oil service. Provides fast, reliable directional control in pneumatic and fluid circuits. In stock in Canada with fast Eastern Canada shipping.

Specifications:

• OEM part number: 78.1342
• Function: 2/2, normally open
• Port: 1/8 in NPT; Cv 0.224 (2.4 mm port)
• Maximum pressure: 200 PSI (2.4 mm port)
• Response time: 16-36 ms (complete cycle)
• Construction: brass body, stainless-steel solenoid operator, Viton seal
• Working temperature: -10°C to 90°C (14°F to 194°F)

Why replace on schedule: a worn solenoid valve can stick or leak and disrupt circuit control; replace per OEM interval. Confirm coil voltage against your equipment before ordering.

Canada Compressor Parts is an independent supplier of genuine Airmax parts. Airmax and all OEM names and part numbers are the property of their respective owners.
