OEM AIRMAX 58.0736

Genuine Airmax Coalescing Filter Element 58.0736

Genuine Airmax compressed-air filter element, OEM part number 58.0736, from the Series 58 filtration range. Grade 07 general coalescing media removes bulk liquid, oil aerosol and fine solids to protect downstream air tools and processes. In stock in Canada with fast Eastern Canada shipping.

Fits (reference — verify by serial or BOM): Airmax Series 58 housing 58.0036.

• OEM part number: 58.0736
• Matching housing: 58.0036

Specifications:

• Filter grade: 07 general coalescing (white element)
• Solid filtration grade: 1 micron
• Oil carryover: 1 ppm w/w
• Maximum liquid loading: 1000 ppm w/w
• Liquid removal efficiency: 99.9%
• Pressure drop: 1 psid dry / 2 psid wet
• Rated capacity: 380 CFM
• Port: 2 in. NPT

Why replace on schedule: a loaded element raises differential pressure and energy cost and lets oil carryover rise; replace per the OEM interval.

Canada Compressor Parts is an independent supplier of genuine Airmax parts. Airmax and all OEM names and part numbers are the property of their respective owners.
