OEM AIRMAX 88.6415

Genuine AIRMAX NFPA Pneumatic Cylinder 88.6415

Genuine AIRMAX Series 88 double-acting NFPA air cylinder, OEM part number 88.6415, with a 3-1/4 in. bore and 15 in. stroke rated to 250 PSI. Delivers repeatable linear actuation for industrial automation and restores rated force output when replacing a worn cylinder. In stock in Canada with fast Eastern Canada shipping.

Fits (reference — verify by serial or BOM): AIRMAX Series 88 NFPA square-head cylinder applications.

• OEM part number: 88.6415

Specifications:

• Bore: 3-1/4 in.
• Stroke: 15 in.
• Maximum working pressure: 250 PSI
• Operating pressure range: 0.05 to 1 MPa
• Theoretical force at 100 PSI: 830 lbs extend / 751 lbs retract
• Speed range: 50 to 500 mm/sec
• Ambient temperature: 5 to 60 C (40 to 140 F), no freezing
• Construction: hard-anodized aluminum tube; oil-filled self-lubricating housing and bushing (no added lubrication required)
• Compliance: mounting per ANSI (NFPA) T3.6.7 R2-1996

Why replace on schedule: a worn cylinder loses sealing and force output, raising air consumption and cycle time; replace per OEM interval.

Canada Compressor Parts is an independent supplier of genuine AIRMAX parts. AIRMAX and all OEM names and part numbers are the property of their respective owners.
