OEM AIRMAX 77.2322

Genuine Airmax Series 77 mechanical air valve 77.2322

Genuine Airmax (Air Max Industries) Series 77 ergonomic low-stress mushroom-type air valve, OEM part number 77.2322, side mount with button guard for manual pneumatic actuation and operator push-button control. Solid zinc body for durable service. Restores rated performance and protects downstream equipment. In stock in Canada with fast Eastern Canada shipping.

• OEM part number: 77.2322

Specifications:

• Port size: 1/8 in NPT (female)
• Function: 3/2 normally closed (invertible to normally open)
• Mounting: side mount with button guard
• Construction: solid zinc
• Cv: 0.24
• Maximum working pressure: 125 PSI
• Working temperature: -18 C to 46 C (0 F to 115 F)
• Red, green and black buttons included

Canada Compressor Parts is an independent supplier of genuine Airmax parts. Airmax and all OEM names and part numbers are the property of their respective owners.
